BZX84-C24

Zener Diodes 250mW 24V

SKU: 15100615-RL1-4.100
Brand:
NXP
Price: Rp 500
Rp 2.000
Specifications:
RoHS:Yes
Vz - Zener Voltage:25.6 V
Mounting Style:SMD/SMT
Package/Case:TO-236AB
Pd - Power Dissipation:250 mW
Voltage Tolerance:5 %
Voltage Temperature Coefficient:20.4 mV/K
Zener Current:50 nA
Zz - Zener Impedance:70 Ohms
Maximum Operating Temperature:+ 150 C
Configuration:Single
Height:1 mm
Ir - Reverse Current:50 nA
Length:2.9 mm
Minimum Operating Temperature:- 55 C
Type:Voltage Regulator
Vf - Forward Voltage:900 mV at 10 mA
Width:1.3 mm
DatasheetSize
BZX84-C24.pdf480.73 KB
