ILD207T VISHAY SOP-6
Rp34.000
Transistor Output Optocouplers Phototransistor Out Dual CTR 100-200%
Stok 49
| RoHS: | Yes |
| Mounting Style: | SMD/SMT |
| Package / Case: | SOIC-8 |
| Number of Channels: | 2 Channel |
| Isolation Voltage: | 4000 Vrms |
| Output Type: | NPN Phototransistor |
| Current Transfer Ratio – Min: | 100% |
| Current Transfer Ratio – Max: | 200% |
| If – Forward Current: | 30 mA |
| Vf – Forward Voltage: | 1.55 V |
| Maximum Collector Emitter Voltage: | 70 V |
| Maximum Collector Current: | 2.5 mA |
| Maximum Collector Emitter Saturation Voltage: | 400 mV |
| Rise Time: | 3 us |
| Fall Time: | 4.7 us |
| Vr – Reverse Voltage: | 6 V |
| Pd – Power Dissipation: | 350 mW |
| Minimum Operating Temperature: | – 55 C |
| Maximum Operating Temperature: | + 100 C |
| Brand: | Vishay Semiconductors |
| Configuration: | 2 Channel |
| Current Transfer Ratio: | 100% |
| Unit Weight: | 0.019048 oz |
