TPS70950DBVR TI SOT-23-5
Rp31.819
LDO Voltage Regulators 150mA 30V Ultra-Lo I Q Wd Input LDO Reg A 595-TPS70950DBVT
| RoHS: | Yes |
| Mounting Style: | SMD/SMT |
| Package/Case: | SOT-23-5 |
| Output Voltage: | 5 V |
| Output Current: | 150 mA |
| Number of Outputs: | 1 Output |
| Polarity: | Positive |
| Quiescent Current: | 1 uA |
| Input Voltage – Min: | 2.7 V |
| Input Voltage – Max: | 30 V |
| PSRR / Ripple Rejection – Typ: | 80 dB |
| Output Type: | Fixed |
| Minimum Operating Temperature: | – 40 C |
| Maximum Operating Temperature: | + 125 C |
| Dropout Voltage: | 300 mV |
| Brand: | Texas Instruments |
| Line Regulation: | 3 mV |
| Load Regulation: | 20 mV |
| Operating Supply Current: | 1 uA |
| Type: | Voltage Linear Regulator with Enable |
| Unit Weight: | 6,300 mg |
